This data logger is engineered to record acceleration data of shock / vibration. It records and time 3-axis vibrations and peaks to provide a history of vibration conditions. The measurement can be either dynamic or static acceleration. Data storage capacity can be up to 85,000 readouts. It is widely applied in engineering & manufacturing environments, shipping & transportation industries, building inspection applications, etc.
- Built-in 3-axis accelerometers record the time of shock occurrences
- Record and time 3-axis shock and peaks
- Real time FFT for frequency analysis
- Measure dynamic and static acceleration
- Optional motion (normal) or freefall detection mode
- Complimentary software for setup, analysis & report generation capabilities
- LEDs signal lights
- User selectable mounting method: Magnet, Screw or Glue
- USB interface for data downloading
- Manual or automatic start
- Vehicle testing
- Building & Construction
- Aerospace
- Ecological
- Acceleration Sensor: MEMS Semiconductor
- Acceleration Range: ±18g
- Acceleration Resolution: 0.00625g
- Calibrated Accuracy: ± 0.5g
- Frequency Range: 0Hz ~ 60Hz
- Data Memory: 4Mbit FLASH（85764 peak acceleration samples and 210 freefall samples）
- Data Format: Time stamped peak acceleration and freefall, average and peak vector sum
- Sampling Rate: 1 second to 24 hours
- Power: 3.6V lithium battery; specs: 14250 or 1/2AAA
- Power Consumption: 1mA (average) recording, <15µA idle
- Battery Life: About 1000 hours
- Computer Interface: USB connection
- Operation Temperature and Humidity: 0°C ~ 40°C; 10%RH ~ 90%RH
- Storage Temperature and Humidity: -10°C ~ +60°C; 10%RH~75%RH
- Dimensions: Pedestal: 106mm x 56mm x 33.5mm; data logger: 95mm x 28mm x 21mm
- System Requirement: Windows 7, 8, 10 & 2000, Vista, XP
- Minimum Hardware Requirement: 8M EMS memory, 2M hard disk, a free USB jack
– 1 x Vibration Data Logger with Cap
– 1 x Mounting Pedestal with Magnets
– 1 x Logging Software on CD
– 1 x 3.6V Lithium Battery
– 3 x Mounting Screw Sets
– 1 x User’s Manual
– 1 x Factory Standard Packing
