AUD $230.00
Need Help? Call 1300 788 213 Now to Talk to an Expert!
This online TDS (Total Dissolved Solids) panel meter is designed to monitor the quality of water or other liquids in real time & continuous way. Measurement range is selectable from 20 to 2000 ppm to suit various applications. It also features with automatic temperature compensation, lengthy PVC cable, durable TDS electrode.
Note: The length of the cable can be customized upon application. Please enquiry with our sales team for confirmation.
- Accurate & fast response indicator
- 4 digits sizable display
- Automatic temperature compensation
- High performance CPU with good electromagnetic compatibility
- Anti-corrosive electrode
- Easy installation
| Measurement Range | 0-20 / 0-200 / 0-2000 ppm |
| Accuracy | 1.5% FS |
| Operating Temperature | 0 – 50 °C |
| Display | 4 digits LCD |
| Temperature Compensation | Automatic temperature compensation with 25°C as the reference temperature |
| Electrode | PVC |
| Working Pressure | 0 – 0.5 MPa |
| Cable | RVP+ Coaxial w/ double shielding |
| Cable Length | 5 meters |
| Fitting | 1/2″ thread |
| Environment Condition | Ambient Temperature: 0 – 50 °C
Relative Humidity: ≤ 85% RH |
| Panel Cut-out (HxW) | 48 x 96 mm |
| Installation | Panel Mounted (Embedded) |
| Power Supply | 220-240 VAC, 50/60 Hz |
| Power Consumption | ≤ 1W |
| Dimensions (HxWxD) | 48 x 96 x 100 mm |
| Weight | 450g |
- 1 x TDS Panel Meter
- 1 x TDS Electrode w/ 5m cable
- 1 x User’s Manual
- 1 x Standard Factory Packing
