AUD $1,085.00
- A professional thermal imaging camera with affordable price
- Overheating measuring
- Used the latest technology with advanced high speed processor to produce the real time image on display
- The touch screen panel for easy operating
- The heat map can be displayed on real image for perfect visualization.
- An automatic photo capture function through the in-built infrared sensor, upon the targeting temperature is over the set point.
- Along with the standard supplied man height adjustable tripod, on-site temperature monitoring has never been easier with only minimum supervision.
- Memory is extendable up to 64GB for numerous data storage.
- All images or videos can be easily viewed or transferred to PC without any software.
If you are looking for a professional thermal imaging camera with affordable price, this device would certainly fulfill both requirements. The newly developed intelligent infrared thermal camera is used the latest technology with advanced high speed processor to produce the real time image on display. Besides the touch screen panel for easy operating, the heat map can be displayed on real image for perfect visualization. It also has an automatic photo capture function through the in-built infrared sensor, upon the targeting temperature is over the set point. Along with the standard supplied man height adjustable tripod, on-site temperature monitoring has never been easier with only minimum supervision. Memory is extendable up to 64GB for numerous data storage. All images or videos can be easily viewed or transferred to PC without any software. In addition to many other great features, this exceptional device will save you lots of time & cost.
- Measurements can be taken by blending between the infrared heat map & visual image with 5 blending levels (0%, 20%, 50%, 75%, 100%).
- 8″ LCD colour touch screen.
- Automatic photo capture function when targeting spot is over the set temperature.
- Combination of real image with infrared heat map function.
- Images are to be saved as .JPG or .PNG files, videos in MP4 format.
- In-built 1GB internal memory with additional SD card slot up to 64GB.
- Hi / Low temperature alarm.
- Adjustable emissivity for various of materials.
- Image or video direct to PC for viewing or downloading, no complicated software required.
- Rugged housing with light weight.
- Complimentary adjustable tripod for fix mount monitoring.
- CE certified with EMC in compliance
- HVAC
- Engineering
- Manufacturing process
- Automotive
- Food processing
| Model | Ti-200 |
| Measuring temperature range | -30 ~ 1000°C |
| Accuracy | ±2% / ±2°C |
| Resolution of infrared image | 32 x 32 (1024) pixels |
| Resolution of visual image | 0.2 megapixels |
| Field angle / Shortest focal distance | 33º x 33º / 5mm |
| Display | 2.8″ LCD colour touch screen |
| Emissivity | 0.1 ~ 1.0 adjustable |
| Sensor | 32 x 32 thermal array, CMOS sensor |
| Thermal sensitivity | 0, 15ºC |
| Image capturing frequency | 6 Hz |
| Range of wavelength | 8 – 11.5 µm |
| Focal distance | Fixed |
| Vision option | 5 variants (0%, 20%, 50%, 75%, 100%). |
| Temperature alert | High / Low alert |
| Blending mode | Hue blending |
| Image format | JPG, PNG |
| Video format | MP4 |
| Internal memory | 1GB |
| External memory | Up to 64GB (micro SD card) |
| Connection | USB interface |
| Operating temperature | -10 ~ 50°C |
| Storage temperature | -20 ~ 60°C |
| Power supply | 3.7V Li-ion rechargeable battery, 2500mAh, Size 18650 |
| Battery life | Approx. 6 hours (it may vary upon capturing time) |
| Auto power off | Approx. 5 mins (adjustable) |
| Housing | Rugged ABS Plastic |
| Dimensions (L*W*H) | 54 x 54 x 218 mm |
– 1 x Intelligent Thermal Camera
– 1 x USB Cable
– 1 x Adjustable Tripod
– 1 x 16G Micro SD Memory Card
– 1 x Power Adapter (AU Type)
– 1 x Operational Manual on CD
– 1 x Carry Case
– 1 x Standard Factory Packing
